Two Sets of PF200(12000LPH) Oil Filter Press sales to Bangladesh

April 3,2025.

The PF200(12000 liters per hour) plate frame Oil Filter Press sales to Bangladesh, which is mainly used for filtration of transformer oil, lube oil, hydraulic oil, turbine oil, gear oil, etc. The main components of PF plate frame oil purifier include hold-down manual devices, filter paper, filter plate, liquid collection tanks, oil pump and electric parts etc. The materials can be carbon stee, stainless steel etc.

How does the PF plate frame oil purifier work:

The suspension is pushed into the filter chamber through the feed pump, and the filtrate is discharged through the groove through the filter papers, and the filter residue forms a filter cake; After filtration, the residue can be cleaned up with water or oil.

The operation of PF plate frame Oil Filter Press is intermittent, which requires manual sludge discharge, cleaning of the filter paper and re-compression. The filtration driving force is large (0.3-0.6 MPa), the solid content of the filter cake is high, and the filtration is fast, which is suitable for liquid and solid separation.

PF plate frame Oil Purifier has the advantage of small-scale, portable, more economical, high filtration efficiency, etc. While traditional equipment achieves high solids cake through intermittent operation, the new patented technology compensates for the lack of manual operation with automated cleaning and vibration descaling. The future direction will focus on improving continuous operation and reducing maintenance costs.
