Case
DVTP100(100LPM) Vacuum Transformer Oil Filtration System Sales to United States
March 31,2026.
We manufacture and sales a set of DVTP100
High Vacuum Transformer Oil Filtration System to United States. When
transformers become damp, maintenance teams often use the hot oil circulation
drying method. The vacuum oil purifier heats the oil to an appropriate
temperature (such as 65-75°C) and injects it into the bottom of the
transformer. As the oil flows through the high-temperature windings, it absorbs
moisture and returns to the transformer oil purification equipment for vacuum
dehydration and degassing. Combined with an external vacuum pump set, this
vacuum–hot oil circulation process can effectively dry the transformer's
internal solid insulation (paperboard), which cannot be achieved by simply
replacing the oil.
Labor costs in the U.S. power industry are extremely high, so DVTP transformer
oil Filtration System is highly automated.
PLC Fully Automatic Control: Modern vacuum oil purifier are generally equipped
with digital PLC controllers and touch screens (HMI), which can automatically
adjust oil level, temperature, and pressure for unattended operation.
Online Processing: For certain critical transformers, the Vacuum Transformer
Oil Purification Equipment is designed to run online at a low flow rate for
extended periods, continuously removing micro water from the oil and
maintaining the oil in optimal condition.
The application of transformer Vacuum Oil Purifier in the U.S. power industry has gone beyond simple filtration and purification. It is a key part of asset health management. By combining diagnostic methods such as dissolved gas analysis (DGA) and dielectric strength testing, vacuum Transformer Oil Filtration System give new life to aging transformers. Whether responding to emergency rentals in extreme weather or serving as a standardized procedure for routine maintenance, this technology supports the U.S. grid's evolution toward greater reliability, efficiency and safety.
