Acore Filtration Co.,Ltd design and manufacgture the MTP150(9000 liters per hour) double stages high vacuum Transformer Oil Purifier and VPS1000 Vacuum Pump System for Guatemala client, The MTP150 vacuum oil purifier mainly is mounted on trailer with weather-proof canopy for filtering processing of dielectric oil at outside and VPS1000 Vacuum Pump System is used for transformer vacuum evacuation before oil filling.

As an efficient vacuum oil purifier, MTP150 double stages high vacuum transformer oil purifier shows excellent performance in the filtering pricessing of waste and new transformer dielectric oils. It adopts advanced two-stage vacuum technology, which separates the water and gas in the oil through the first-stage vacuum, and then further removes the residual trace moisture and gas through the second-stage vacuum, while using the fine filtration system to remove solid particle impurities in the oil. This two-stage purification process enables deep purification of the oil, restores the physical and chemical properties of the oil, and prolongs the life of the oil.

Before oil filling into transfomers, the user should do vacuum evacuation for transformer by VPS1000 vacuum pump system. After reaching required vacuum value, user can use MTP150 Vacuum Oil Purifier to fill the oil into transformer. In the power industry, the purification of transformer oil is essential to ensure the insulation performance and cooling effect of the transformer. The Transformer Oil Purifier and Vacuum Pump System can cooperate to prolong the service life of the transformer and keep stability of power industry.
